Specifications
- Fabrika Tedarik Süresi
- 4 Weeks
- Studtab Size
- 1/2 Stud
- Terminal Style
- Two Stud Holes
- HTS Kodu
- 8536.90.40.00
- ECCN Kodu
- EAR99
- Insulation
- Non-Insulated
- Contact Materials
- Copper
- Radyasyon Dayanımı
- No
- Width Outer Edges
- 2.170 55.12mm
- Length Overall
- 7.290 185.17mm
- Body Plating
- Tin
- Wire Gauge
- 1000MCM (kcmil)
- Tab Thickness
- 0.320 8.13mm
- Diameter Barrel Od
- 1.500 (38.10mm)
- Renk
- White
- Uzunluk
- 185.166mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Contact Finish
- Electro-Tin
- Wire Cross Section
- 506.6 mm2
- Ambalaj
- Bulk
- Yayın Yılı
- 2004
- Parça Durumu
- Active
- Terminal And Terminal Block Type
- WIRE TERMINAL
- Depth
- 55.1mm
- RoHS Durumu
- ROHS3 Compliant
- Terminal Type
- Rectangular Tongue
- Montaj Tipi
- Free Hanging (In-Line)
- Diameter Barrel Id
- 1.170 (29.72mm)
- Diameter Ring Id
- 0.530 (13.46mm)
- Terminal
- Crimp, Barrel
- Montaj
- Free Hanging
- Terminal Gender
- FEMALE
- Seri
- Pan-Lug®
