Specifications
- Radyasyon Dayanımı
- No
- Width Outer Edges
- 1.170 29.72mm
- HTS Kodu
- 8536.90.40.00
- ECCN Kodu
- EAR99
- Insulation
- Non-Insulated
- Contact Materials
- Copper
- Fabrika Tedarik Süresi
- 4 Weeks
- Studtab Size
- 1/2 Stud
- Terminal Style
- Single Stud Hole
- Ambalaj
- Bulk
- Yayın Yılı
- 2004
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Cross Section
- 126.6 mm2
- Contact Finish
- Electro-Tin
- Tab Thickness
- 0.140 3.56mm
- Diameter Barrel Od
- 0.770 (19.56mm)
- Renk
- Yellow
- Uzunluk
- 84.328mm
- Length Overall
- 3.320 84.33mm
- Body Plating
- Tin
- Wire Gauge
- 250MCM (kcmil)
- Diameter Barrel Id
- 0.630 (16.00mm)
- Diameter Ring Id
- 0.530 (13.46mm)
- Terminal
- Crimp, Barrel
- Terminal Type
- Rectangular Tongue
- Montaj Tipi
- Free Hanging (In-Line)
- Terminal And Terminal Block Type
- WIRE TERMINAL
- Depth
- 29.71mm
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Seri
- Pan-Lug®
- Terminal Gender
- FEMALE
- Montaj
- Free Hanging
