Specifications
- Diameter Barrel Id
- 0.180 (4.57mm)
- Uzunluk
- 42.164mm
- HTS Kodu
- 8536.90.40.00
- Depth
- 14.22mm
- Montaj Tipi
- Free Hanging (In-Line)
- Kurşunsuz Kodu
- yes
- Montaj
- Free Hanging
- Studtab Size
- 5/16 Stud
- Fabrika Tedarik Süresi
- 4 Weeks
- Radyasyon Dayanımı
- No
- Contact Finish
- Electro-Tin
- Tab Thickness
- 0.050 1.27mm
- ECCN Kodu
- EAR99
- Terminal
- Crimp, Barrel
- Wire Gauge
- 8 AWG
- Parça Durumu
- Active
- Wirecable Gauge
- 8 AWG
- Seri
- Pan-Lug®
- Terminal Style
- Single Stud Hole
- Length Overall
- 1.660 42.16mm
- Body Plating
- Tin
- Width Outer Edges
- 0.560 14.22mm
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yayın Yılı
- 2004
- Renk
- Red
- Terminal And Terminal Block Type
- RING TERMINAL
- Diameter Barrel Od
- 0.320 (8.13mm)
- Diameter Ring Id
- 0.340 (8.64mm)
- Contact Materials
- Copper
- Terminal Type
- Rectangular Tongue
- Insulation
- Non-Insulated
- RoHS Durumu
- ROHS3 Compliant
