Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Tab Thickness
- 0.140 3.56mm
- Contact Finish
- Electro-Tin
- Radyasyon Dayanımı
- No
- Terminal
- Crimp, Barrel
- ECCN Kodu
- EAR99
- Uzunluk
- 71.88mm
- HTS Kodu
- 8536.90.40.00
- Gender
- Female
- Depth
- 26.92mm
- Diameter Barrel Id
- 0.570 (14.48mm)
- Studtab Size
- 1/2 Stud
- Fabrika Tedarik Süresi
- 4 Weeks
- Montaj
- Stud
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Free Hanging (In-Line)
- Diameter Ring Id
- 0.530 (13.46mm)
- Diameter Barrel Od
- 0.810 (20.57mm)
- Contact Materials
- Copper
- Renk
- Purple
- Terminal And Terminal Block Type
- RING TERMINAL
- Insulation
- Non-Insulated
- RoHS Durumu
- ROHS3 Compliant
- Wire Gauge Max
- 0 AWG
- Terminal Type
- Lug, Grounding
- Terminal Style
- Single Stud Hole
- Seri
- Pan-Lug®
- Wire Gauge
- 3/0 AWG
- Parça Durumu
- Active
- Yayın Yılı
- 2004
- Weight
- 591.938043g
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Min
- 3 AWG
- Length Overall
- 2.830 71.88mm
- Width Outer Edges
- 1.060 26.92mm
- Body Plating
- Tin
