Specifications
- Terminal Type
- Rectangular Tongue
- Renk
- Blue
- Diameter Ring Id
- 0.340 (8.64mm)
- Radyasyon Dayanımı
- No
- Length Overall
- 1.730 43.94mm
- Ambalaj
- Bulk
- Montaj
- Free Hanging
- Montaj Tipi
- Free Hanging (In-Line)
- Tab Thickness
- 0.070 1.78mm
- HTS Kodu
- 8535.90.80.20
- Terminal Style
- Single Stud Hole
- Seri
- Pan-Lug®
- Gender
- Female
- Diameter Barrel Od
- 0.310 (7.87mm)
- Studtab Size
- 5/16 Stud
- Insulation
- Non-Insulated
- Depth
- 14.22mm
- Orientation
- Straight
- Body Plating
- Tin
- Terminal And Terminal Block Type
- RING TERMINAL
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Gauge
- 6 AWG
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Weight
- 480.807912g
- Contact Materials
- Copper
- Uzunluk
- 43.942mm
- Yayın Yılı
- 2008
- Nem Hassasiyeti (MSL)
- Not Applicable
- Width Outer Edges
- 0.560 14.22mm
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Terminal
- Crimp, Barrel
- Diameter Barrel Id
- 0.220 (5.59mm)
- Wirecable Gauge
- 6 AWG
- Contact Finish
- Electro-Tin
