Specifications
- Width Outer Edges
- 1.540 39.12mm
- Contact Materials
- Copper
- Uzunluk
- 108.204mm
- Yayın Yılı
- 2004
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal And Terminal Block Type
- RING TERMINAL
- Fabrika Tedarik Süresi
- 4 Weeks
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Wire Gauge
- 500MCM (kcmil)
- Contact Finish
- Electro-Tin
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Diameter Barrel Id
- 0.840 (21.34mm)
- Terminal
- Crimp, Barrel
- Length Overall
- 4.260 108.20mm
- Montaj Tipi
- Free Hanging (In-Line)
- Montaj
- Free Hanging
- Ambalaj
- Bulk
- Terminal Type
- Rectangular Tongue
- Radyasyon Dayanımı
- No
- Diameter Ring Id
- 1.030 (26.16mm)
- Renk
- Brown
- Insulation
- Non-Insulated
- Contact Plating
- Tin
- Tab Thickness
- 0.220 5.59mm
- HTS Kodu
- 8536.90.40.00
- Terminal Style
- Single Stud Hole
- Diameter Barrel Od
- 1.060 (26.92mm)
- Studtab Size
- 1 Stud
- Seri
- Pan-Lug®
