Specifications
- Contact Materials
- Copper
- Yayın Yılı
- 2008
- Nem Hassasiyeti (MSL)
- Not Applicable
- Uzunluk
- 61.976mm
- Width Outer Edges
- 1.060 26.92mm
- Terminal And Terminal Block Type
- RING TERMINAL
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Gauge
- 4/0 AWG
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Contact Finish
- Electro-Tin
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Terminal
- Crimp, Barrel
- Diameter Barrel Id
- 0.570 (14.48mm)
- Length Overall
- 2.440 61.98mm
- Ambalaj
- Bulk
- Montaj
- Free Hanging
- Montaj Tipi
- Free Hanging (In-Line)
- Terminal Type
- Rectangular Tongue
- Renk
- Purple
- Diameter Ring Id
- 0.410 (10.41mm)
- Radyasyon Dayanımı
- No
- Insulation
- Non-Insulated
- Depth
- 26.92mm
- Orientation
- Straight
- Body Plating
- Tin
- HTS Kodu
- 8536.90.40.00
- Tab Thickness
- 0.140 3.56mm
- Terminal Style
- Single Stud Hole
- Seri
- Pan-Lug®
- Diameter Barrel Od
- 0.710 (18.03mm)
- Studtab Size
- 3/8 Stud
