Specifications
- Wirecable Gauge
- 10 AWG
- Wire Gauge Min
- 14 AWG
- Montaj
- Free Hanging
- Tab Thickness
- 0.050 1.27mm
- Width Outer Edges
- 0.420 10.67mm
- Contact Plating
- Tin
- Renk
- Silver
- Weight
- 188.240834g
- Studtab Size
- 1/4 Stud
- Gender
- Female
- Terminal Type
- Lug, Grounding
- Contact Finish
- Electro-Tin
- Wire Gauge
- 10 AWG
- Kurşunsuz Kodu
- yes
- Contact Materials
- Copper
- Terminal And Terminal Block Type
- RING TERMINAL
- Length Overall
- 1.160 29.46mm
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 29.464mm
- HTS Kodu
- 8536.90.40.00
- Insulation
- Non-Insulated
- Yayın Yılı
- 2004
- Diameter Ring Id
- 0.270 (6.86mm)
- Montaj Tipi
- Free Hanging (In-Line)
- Seri
- Pan-Lug®
- Diameter Barrel Id
- 0.130 (3.30mm)
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ambalaj
- Bulk
- Thickness
- 50μm
- Parça Durumu
- Active
- Wire Gauge Max
- 10 AWG
- Terminal
- Crimp, Barrel
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 4 Weeks
- Diameter Barrel Od
- 0.220 (5.59mm)
- Terminal Style
- Single Stud Hole
- Radyasyon Dayanımı
- No
