Specifications
- Max Supply Voltage Dc
- 24V
- Ambalaj
- Bulk
- Terminal
- Cable
- Çalışma Sıcaklığı
- -25°C~55°C
- Voltage Collector Emitter Breakdown Max
- 30V
- Additional Feature
- REVERSE POLARITY, SHORT CIRCUIT PROTECTION
- Algılama Mesafesi
- 0.197 (5mm)
- Montaj
- Chassis Mount
- Min Supply Voltage Dc
- 5V
- Body Height
- 28.2mm
- Tip
- Unamplified
- Currentcollector Ic Max
- 15mA
- Repeatability
- 0.03
- Touchscreen
- Infrared (IR)
- Montaj Tipi
- Chassis Mount
- Reach Svhc
- Unknown
- Sensing Method
- Through-Beam
- Seri
- PM-44
- Output Current
- 50mA
- Kılıf / Paket
- Module, Wire Leads, Slot Type
- Output Configuration
- NPN - Dark-ON/Light-ON - Selectable
- Body Length Or Diameter
- 26mm
- Yayın Yılı
- 2003
- Response Time
- 20μs
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Obsolete
- Output Range
- 50mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Measurement Rangemax
- 5 mm
- Body Breadth
- 13.7 mm
