Specifications
- Measurement Rangemax
- 5 mm
- Body Breadth
- 18.5 mm
- Supply Voltagemin Vsup
- 5V
- Parça Durumu
- Obsolete
- Output Range
- 50mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2008
- Response Time
- 20μs
- Output Configuration
- NPN - Dark-ON/Light-ON - Selectable
- Body Length Or Diameter
- 26mm
- Kurşunsuz
- Lead Free
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Sensing Method
- Through-Beam
- Seri
- PM-44
- Montaj Tipi
- Chassis Mount
- Kılıf / Paket
- Module, Wire Leads, Slot Type
- Output Current
- 50mA
- Touchscreen
- Infrared (IR)
- Currentcollector Ic Max
- 15mA
- Repeatability
- 0.03
- Montaj
- Chassis Mount
- Body Height
- 20.5mm
- Tip
- Unamplified
- Supply Voltagemax Vsup
- 24V
- Terminal
- Cable
- Ambalaj
- Bulk
- Algılama Mesafesi
- 0.197 (5mm)
- Çalışma Sıcaklığı
- -25°C~55°C
- Voltage Collector Emitter Breakdown Max
- 30V
- Additional Feature
- REVERSE POLARITY, SHORT CIRCUIT PROTECTION
