PM-L25-C3

Specifications

Parça Durumu

Active

Repeatability

0.01

Nem Hassasiyeti (MSL)

1 (Unlimited)

Kılıf / Paket

Module, Wire Leads, Slot Type

Housing

PLASTIC

Seri

PM-25

Sensing Method

Through-Beam

Montaj Tipi

Chassis Mount

Algılama Mesafesi

0.236 (6mm)

Çalışma Sıcaklığı

-25°C~55°C TA

Besleme Gerilimi

5V~24V

Additional Feature

IP64, SHORT-CIRCUIT PROTECTION, IT ALSO HAVE UNDER LIGHT RECEIVED CONDITION RESPONSE TIME OF 20 MICRO SECOND

Fabrika Tedarik Süresi

8 Weeks

Operating Supply Current

15mA

REACH Uyumluluk Kodu

unknown

RoHS Durumu

RoHS Compliant

Yayın Yılı

2016

Response Time

20μs

Termination Type

CABLE

Output Configuration

NPN - Open Collector

Montaj

Chassis Mount
