Specifications
- Current Dc Forward If Max
- 50mA
- RoHS Durumu
- RoHS Compliant
- Operating Supply Current
- 15mA
- REACH Uyumluluk Kodu
- unknown
- Kurşunsuz
- Lead Free
- Body Length Or Diameter
- 22mm
- Output Configuration
- NPN - Dark-ON/Light-ON - Selectable
- Yayın Yılı
- 2003
- Response Time
- 20μs
- Parça Durumu
- Obsolete
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polybutylene
- Body Breadth
- 6 mm
- Measurement Rangemax
- 5 mm
- Çalışma Sıcaklığı
- -25°C~55°C
- Voltage Collector Emitter Breakdown Max
- 30V
- Additional Feature
- REVERSE POLARITY, SHORT CIRCUIT PROTECTION
- Algılama Mesafesi
- 0.197 (5mm)
- Max Supply Voltage Dc
- 24V
- Ambalaj
- Bulk
- Terminal
- Cable
- Body Height
- 14mm
- Tip
- Unamplified
- Montaj
- Chassis Mount, Screw
- Min Supply Voltage Dc
- 5V
- Repeatability
- 0.03
- Touchscreen
- Infrared (IR)
- Output Current
- 50mA
- Kılıf / Paket
- Module, Wire Leads, Slot Type
- Montaj Tipi
- Chassis Mount
- Seri
- PM-24
- Sensing Method
- Through-Beam
