Specifications
- Body Breadth
- 13.2 mm
- Measurement Rangemax
- 5 mm
- Housing Material
- Polybutylene
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Output Range
- 50mA
- Parça Durumu
- Obsolete
- Response Time
- 20μs
- Yayın Yılı
- 2003
- Output Configuration
- NPN - Dark-ON/Light-ON - Selectable
- Body Length Or Diameter
- 13.4mm
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Seri
- PM-44
- Sensing Method
- Through-Beam
- Reach Svhc
- No SVHC
- Montaj Tipi
- Chassis Mount
- Kılıf / Paket
- Module, Wire Leads, Slot Type
- Output Current
- 50mA
- Max Voltage Rating Dc
- 24V
- Touchscreen
- Infrared (IR)
- Repeatability
- 0.03
- Currentcollector Ic Max
- 15mA
- Min Supply Voltage Dc
- 5V
- Montaj
- Chassis Mount, Screw
- Tip
- Unamplified
- Body Height
- 28.2mm
- Terminal
- Cable
- Ambalaj
- Bulk
- Max Supply Voltage Dc
- 24V
- Algılama Mesafesi
- 0.197 (5mm)
- Additional Feature
- REVERSE POLARITY, SHORT CIRCUIT PROTECTION
- Çalışma Sıcaklığı
- -25°C~55°C
- Voltage Collector Emitter Breakdown Max
- 30V
