Specifications
- Switchingfrequency
- 52kHz
- Min Supply Voltage
- 4.5V
- Uzunluk
- 11mm
- Output Configuration
- Half Bridge (4)
- Step Resolution
- 1, 1/2, 1/8, 1/16
- Max Output Current
- 800mA
- Collector Emitter Voltage Vceo
- 37V
- Max Collector Current
- 800mA
- Çalışma Sıcaklığı
- -20°C~120°C TJ
- Ambalaj
- Tape & Reel (TR)
- Number Of Outputs
- 2
- Interface
- Parallel, PWM
- Nominal Supply Current
- 6mA
- Yayın Yılı
- 2012
- Logic Function
- AND
- Genişlik
- 6.1mm
- Reach Svhc
- Unknown
- Pin Sayısı
- 32
- Yükseklik
- 1.4mm
- Besleme Gerilimi
- 4.5V~5.5V
- Fabrika Tedarik Süresi
- 11 Weeks
- Min. Çalışma Sıcaklığı
- -20°C
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Applications
- General Purpose
- Maks. Çalışma Sıcaklığı
- 70°C
- Function
- Driver - Fully Integrated, Control and Power Stage
- Tedarikçi Cihaz Paketi
- 32-SSOP
- Motor Type
- Stepper
- Voltage Load
- 16V~34V
- Montaj
- Surface Mount
- Motor Type Stepper
- Bipolar
- Power Dissipation
- 427mW
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Surface Mount
- Output Voltage
- 37V
- Kılıf / Paket
- 32-SSOP (0.240, 6.10mm Width)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Supply Voltage
- 5.5V
- Temel Parça No
- AN44063A
