Specifications
- HTS Kodu
- 8536.49.00.50
- Relay Type
- Telecom
- Contact Dc Max Rating R Load
- 2A@220VDC
- ECCN Kodu
- EAR99
- Operate Time
- 4ms
- RoHS Durumu
- RoHS Compliant
- Terminal Sayısı
- 10
- Seal Rating
- Sealed - Fully
- Physical Dimension
- 15mm x 7.4mm x 8.2mm
- Packing Method
- TUBE
- Reference Standard
- BSI; CSA; UL
- Coil Voltage Dc
- 12V
- Pin Sayısı
- 10
- Kontak Formu
- DPDT (2 Form C)
- Yayın Yılı
- 2000
- Must Operate Voltage
- 9VDC
- Terminal
- Solder
- Contact Materials
- Silver (Ag), Gold (Au)
- Switching Voltage
- 220VDC -Max
- Terminal Stili
- PC Pin
- Sealing
- WATER PROOF
- Length Termination
- 0.0035 inch
- Contactoutput Supply Type
- DC
- Release Time
- 4 ms
- Power Consumption
- 200mW
- Weight
- 2g
- Body Breadth
- 7.4 mm
- Max Current Rating
- 2A
- Seri
- TX
- Coil Voltage
- 12VDC
- Max Voltage Rating Dc
- 220V
- Contact Currentdcmax
- 2A
- Throw Configuration
- DPDT
- Ambalaj
- Box
- Contact Dc Max Power Rating R Load
- 60W@220VDC
- Montaj
- Through Hole
- Fabrika Tedarik Süresi
- 18 Weeks
- Relay Action
- LATCHED
- Dielectric Strength Between Coil And Contacts
- 2000 Vrms
- Parça Durumu
- Active
