Volume pricing
- 1+ pcs$34.13
- 10+ pcs$32.20
- 100+ pcs$30.38
- 500+ pcs$28.66
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Power Consumption
- 300mW
- Dielectric Strength Between Open Contacts
- 1500 Vrms
- Seri
- SP
- Yayın Yılı
- 1998
- Yükseklik
- 20.5mm
- Kurşunsuz Kodu
- yes
- Coilinput Supply Type
- DC
- Max Current Rating
- 10A
- Terminal Sayısı
- 16
- HTS Kodu
- 8536.41.00.20
- Switching Voltage
- 250VAC 30VDC -Max
- Coil Type
- Non Latching
- Contact Resistance
- 30mOhm
- Dielectric Strength Between Coil And Contacts
- 3000 Vrms
- Coil Power
- 300mW
- Reference Standard
- CSA; TUV; UL
- Coilresistance
- 480Ohm
- Must Release Voltage
- 1.2VDC
- Montaj
- Through Hole
- Voltage Rated Dc
- 30V
- Relay Type
- General Purpose
- Max Voltage Rating Dc
- 30V
- Pin Sayısı
- 14
- Contact Materials
- Silver Tin Oxide (AgSnO)
- Genişlik
- 50mm
- RoHS Durumu
- RoHS Compliant
- Power Rating
- 300mW
- Coil Current
- 25mA
- Throw Configuration
- 4PDT
- ECCN Kodu
- EAR99
- Radyasyon Dayanımı
- No
- Operate Time
- 30ms
- Electricallife
- 100000 Cycle(s)
- Relay Action
- MOMENTARY
- Release Time
- 20ms
- Montaj Tipi
- Through Hole
- Physical Dimension
- 50mm x 36.8mm x 22mm
- Reach Svhc
- No SVHC
- Uzunluk
- 51mm
- End Contact Plating
- GOLD
