Specifications
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Physical Dimension
- 31mm x 28.5mm x 16.8mm
- Depth
- 28.5mm
- Switching Voltage
- 250VAC -Max
- Coilinput Supply Type
- DC
- Must Release Voltage
- 2.4VDC
- Throw Configuration
- SPST
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Chassis Mount
- Power Consumption
- 900mW
- Max Current Rating
- 20A
- Coil Current
- 37.5mA
- Contactoutput Supply Type
- AC
- Weight
- 30g
- Coilresistance
- 640Ohm
- Terminal Stili
- Quick Connect - 0.187/0.250
- Packing Method
- BOX
- Body Height
- 16.8mm
- Coil Type
- Non Latching
- Uzunluk
- 47.5mm
- Relay Action
- MOMENTARY
- Contact Materials
- Silver Tin Oxide (AgSnO)
- Montaj Tipi
- Chassis Mount
- Seri
- JM
- Coil Voltage
- 24VDC
- Parça Durumu
- Obsolete
- Ambalaj
- Tube
- Electricallife
- 100000 Cycle(s)
- RoHS Durumu
- RoHS Compliant
- Reference Standard
- CSA; TUV; UL; VDE
- Must Operate Voltage
- 16.8VDC
- Contact Ac Max Rating R Load
- 20A@250VAC
- Max Voltage Rating Ac
- 250V
- Çalışma Sıcaklığı
- -40°C~60°C
- Kontak Formu
- SPST-NO (1 Form A)
- Voltage Rated Ac
- 250V
- Pin Sayısı
- 4
- Coil Power
- 900mW
- Yayın Yılı
- 2003
