Specifications
- Coil Voltage
- 24VDC
- Coil Voltage Dc
- 24V
- Terminal Stili
- PC Pin
- Kontak Formu
- DPST-NO/NC (1 Form A, 1 Form B)
- ECCN Kodu
- EAR99
- Coil Current
- 12.5mA
- Max Current Rating
- 5A
- Power Consumption
- 300mW
- Seri
- DSP
- Coilresistance
- 1.92kOhm
- Max Voltage Rating Ac
- 250V
- Body Breadth
- 11 mm
- Release Time
- 5ms
- Contact Currentdcmax
- 5A
- Montaj Tipi
- Through Hole
- Reference Standard
- CSA; TUV; UL
- Akım Değeri
- 5A
- Body Height
- 10.5mm
- Body Length Or Diameter
- 20.2mm
- Must Release Voltage
- 2.4VDC
- Contact Currentacmax
- 5A
- Contact Dc Max Rating R Load
- 5A@30VDC
- Kurşunsuz Kodu
- yes
- Seal Rating
- Sealed - Fully
- Contactoutput Supply Type
- AC/DC
- Contact Materials
- Silver Tin Oxide (AgSnO)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operate Time
- 10ms
- Power Rating
- 300mW
- Electricallife
- 100000 Cycle(s)
- Coilinput Supply Type
- DC
- Relay Action
- MOMENTARY
- Relay Type
- General Purpose
- Packing Method
- BOX
- REACH Uyumluluk Kodu
- unknown
- Montaj
- Through Hole
- Yayın Yılı
- 2000
- Throw Configuration
- DPST, SPST
- Pin Sayısı
- 6
- Contact Ac Max Rating R Load
- 5A@250VAC
