Specifications
- Seal Rating
- Sealed - Fully
- Switching Current
- 2A
- Electricallife
- 500000 Cycle(s)
- Coil Power
- 360mW
- Rise Time
- 3ms
- Uzunluk
- 15mm
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz Kodu
- yes
- Contact Ac Max Rating R Load
- 2A@250VAC
- Contact Dc Max Rating R Load
- 2A@30VDC
- Coilresistance
- 1.6kOhm
- Kılıf / Paket
- DIP
- Voltage Rated Dc
- 220V
- Montaj
- Through Hole
- Throw Configuration
- SPDT
- Terminal Stili
- PC Pin
- Physical Dimension
- 15mm x 9.9mm x 9.9mm
- Must Operate Voltage
- 16.8VDC
- Coil Voltage Dc
- 24V
- Relay Action
- LATCHED
- Pin Sayısı
- 6
- Contact Currentdcmax
- 2A
- Kontak Formu
- SPDT (1 Form C)
- Contact Currentacmax
- 2A
- Relay Type
- General Purpose
- Fabrika Tedarik Süresi
- 10 Weeks
- Ratings
- IP67
- Terminal
- PC Pin
- ECCN Kodu
- EAR99
- Coil Voltage
- 24VDC
- Sealing
- EPOXY RESIN SEALED
- Yayın Yılı
- 2000
- Coil Type
- Latching, Dual Coil
- Seri
- DS
- Depth
- 9.9mm
- Voltage Rated Ac
- 250V
- Weight
- 3g
- Contact Materials
- Silver (Ag), Gold (Au)
- Operate Time
- 10ms
- Coil Current
- 15mA
