Specifications
- Throw Configuration
- SPST
- Must Operate Voltage
- 3.5VDC
- Contact Materials
- Silver Tin Oxide (AgSnO)
- Ambalaj
- Tube
- Body Height
- 12mm
- Coil Voltage
- 5VDC
- ECCN Kodu
- EAR99
- Must Release Voltage
- 0.5VDC
- Physical Dimension
- 25mm x 12.5mm x 12mm
- Pin Sayısı
- 6
- Coil Power
- 200mW
- Release Time
- 5ms
- Weight
- 7g
- Terminal Stili
- PC Pin
- Switching Voltage
- 250VAC 30VDC -Max
- Max Current Rating
- 10A
- Coil Voltage Dc
- 5V
- Kontak Formu
- SPST-NO (1 Form A)
- Test Voltage
- 5kV
- Contact Dc Max Rating R Load
- 10A@30VDC
- Relay Action
- MOMENTARY
- Ratings
- IP67
- Çalışma Sıcaklığı
- -40°C~70°C
- Switching Current
- 10A
- Terminal
- PC Pin
- Coilresistance
- 125Ohm
- RoHS Durumu
- RoHS Compliant
- Switching Capacity
- 300 W
- Yayın Yılı
- 2000
- Parça Durumu
- Active
- Coil Type
- Non Latching
- Seri
- DE
- Pitch
- 2.54mm
- Body Length Or Diameter
- 25mm
- Relay Type
- General Purpose
- Contact Ac Max Rating R Load
- 10A@250VAC
- Max Voltage Rating Ac
- 440V
- Power Consumption
- 200mW
- Max Voltage Rating Dc
- 230V
- Montaj
- Through Hole
