Specifications
- Ambalaj
- Tube
- Body Height
- 12mm
- Coil Voltage
- 5VDC
- Throw Configuration
- DPST, SPST
- Length Termination
- 0.0035 inch
- Contact Resistance
- 30mOhm
- Must Operate Voltage
- 3.5VDC
- Contact Materials
- Silver Tin Oxide (AgSnO)
- Coil Power
- 100mW
- Release Time
- 5ms
- Weight
- 7g
- Terminal Sayısı
- 6
- ECCN Kodu
- EAR99
- Physical Dimension
- 25mm x 12.5mm x 12mm
- Pin Sayısı
- 6
- Relay Form
- 1 FORM A,B
- Contact Currentacmax
- 8A
- Coil Voltage Dc
- 5V
- Terminal Stili
- PC Pin
- Contact Currentdcmax
- 8A
- Switching Voltage
- 250VAC 30VDC -Max
- Contact Dc Max Power Rating R Load
- 240W@230VDC
- Max Current Rating
- 8A
- Ratings
- IP67
- Switching Current
- 8A
- Çalışma Sıcaklığı
- -40°C~70°C
- Terminal
- PC Pin
- Coilresistance
- 250Ohm
- Pcb Hole Count
- 6
- Test Voltage
- 5kV
- Kontak Formu
- DPST-NO/NC (1 Form A, 1 Form B)
- Contact Ac Max Power Rating R Load
- 2000VA@440VAC
- Relay Action
- LATCHED
- Contact Dc Max Rating R Load
- 8A@30VDC
- Seri
- DE
- Pitch
- 2.54mm
- Genişlik
- 12.5mm
- Body Length Or Diameter
- 25mm
- Relay Type
- General Purpose
- RoHS Durumu
- RoHS Compliant
