Volume pricing
- 1+ pcs$8.23
- 10+ pcs$7.76
- 100+ pcs$7.32
- 500+ pcs$6.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Coil Voltage Dc
- 24V
- Contact Currentacmax
- 8A
- Relay Form
- 1 FORM A,B
- Max Current Rating
- 8A
- Contact Dc Max Power Rating R Load
- 240W@230VDC
- Switching Voltage
- 250VAC 30VDC -Max
- Contact Currentdcmax
- 8A
- Terminal Stili
- PC Pin
- Coilresistance
- 2.88kOhm
- Terminal
- PC Pin
- Çalışma Sıcaklığı
- -40°C~70°C
- Switching Current
- 8A
- Ratings
- IP67
- Relay Action
- LATCHED
- Kontak Formu
- DPST-NO/NC (1 Form A, 1 Form B)
- Test Voltage
- 5kV
- Contact Ac Max Power Rating R Load
- 2000VA@440VAC
- Pcb Hole Count
- 6
- Body Height
- 12mm
- Coil Voltage
- 24VDC
- Ambalaj
- Tube
- Contact Resistance
- 30mOhm
- Must Operate Voltage
- 16.8VDC
- Contact Materials
- Silver Tin Oxide (AgSnO)
- Length Termination
- 0.0035 inch
- Throw Configuration
- DPST, SPST
- Weight
- 9g
- Release Time
- 5ms
- Coil Power
- 200mW
- Physical Dimension
- 25mm x 12.5mm x 12mm
- Pin Sayısı
- 8
- ECCN Kodu
- EAR99
- Terminal Sayısı
- 6
- Body Breadth
- 12.5 mm
- Contactoutput Supply Type
- AC/DC
- Coil Current
- 8.3mA
- Operate Time
- 10ms
- Reach Svhc
- Unknown
- Dielectric Strength Between Open Contacts
- 1000 Vrms
- Montaj Tipi
- Through Hole
