Specifications
- Must Release Voltage
- 2.4VDC
- Parça Durumu
- Active
- Relay Type
- Automotive
- Must Operate Voltage
- 14VDC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contactoutput Supply Type
- DC
- Özellikler
- Sealed - Flux Protection
- Max Current Rating
- 20A
- Contact Currentdcmax
- 1A
- Max Voltage Rating Dc
- 28V
- Montaj Tipi
- Socketable
- Coilresistance
- 320Ohm
- Packing Method
- BOX
- Pin Sayısı
- 4
- Çalışma Sıcaklığı
- -40°C~85°C
- Fabrika Tedarik Süresi
- 16 Weeks
- Kurşunsuz
- Lead Free
- Coil Power
- 1800mW
- Physical Dimension
- 26mm x 22mm x 25mm
- Release Time
- 15 ms
- Kontak Formu
- SPST-NO (1 Form A)
- Electricallife
- 100000 Cycle(s)
- Coil Voltage
- 24VDC
- Sealing
- FLUX FREE SEALED
- Throw Configuration
- SPST
- Body Height
- 25mm
- Yayın Yılı
- 2000
- Terminal
- Quick Connect
- Coil Voltage Dc
- 24V
- Terminal Stili
- Plug In, Quick Connect - 0.250 (6.3mm)
- Uzunluk
- 26mm
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Switching Voltage
- 28VDC - Nom
- Coilinput Supply Type
- DC
- Power Consumption
- 1.8W
- Coil Type
- Non Latching
- Weight
- 33g
- Montaj
- Plug-In, Socketable
- Relay Action
- MOMENTARY
