Specifications
- Contact Finish
- Gold
- Height Above Board
- 0.035 0.88mm
- Current Rating Amps
- 0.2A per Contact
- Terminal
- Solder
- Actuator Material
- Liquid Crystal Polymer (LCP)
- Montaj
- Surface Mount
- Locking Feature
- Flip Lock, Backlock
- Çalışma Sıcaklığı
- -55°C~85°C
- Flat Flex Type
- FPC
- Contact Resistance
- 100mOhm
- Ffc Fcb Thickness
- 0.20mm
- Max Voltage Rating Ac
- 50V
- Montaj Tipi
- Surface Mount, Right Angle
- RoHS Durumu
- RoHS Compliant
- Mating Cycles
- 20
- Contact Materials
- Copper Alloy
- Depth
- 2.95mm
- Material Flammability Rating
- UL94 V-0
- Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 1
- Ambalaj
- Bulk
- Akım Değeri
- 200mA
- Yayın Yılı
- 2008
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pozisyon Sayısı
- 11
- Seri
- Y3B
- Pitch
- 0.012 0.30mm
- Uzunluk
- 4.8mm
- Cable End Type
- Tapered
- Contact Finish Thickness
- Flash
- Orientation
- Right Angle
- Parça Durumu
- Not For New Designs
- Fabrika Tedarik Süresi
- 8 Weeks
- Housing Material
- Liquid Crystal Polymer (LCP)
