Volume pricing
- 1+ pcs$0.55
- 10+ pcs$0.52
- 100+ pcs$0.49
- 500+ pcs$0.46
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuator Material
- Liquid Crystal Polymer (LCP)
- Terminal
- Solder
- Çalışma Sıcaklığı
- -55°C~85°C
- Locking Feature
- Flip Lock, Backlock
- Montaj
- Surface Mount
- Height Above Board
- 0.035 0.88mm
- Contact Finish
- Gold
- Current Rating Amps
- 0.2A per Contact
- Filter Feature
- NO
- Flat Flex Type
- FPC
- Additional Feature
- LOW PROFILE
- Montaj Tipi
- Surface Mount, Right Angle
- Din Conformance
- NO
- RoHS Durumu
- RoHS Compliant
- HTS Kodu
- 8536.69.40.51
- Contact Resistance
- 100mOhm
- Ffc Fcb Thickness
- 0.20mm
- Max Voltage Rating Ac
- 50V
- Contact Materials
- Copper Alloy
- Depth
- 3.15mm
- Mating Cycles
- 20
- Material Flammability Rating
- UL94 V-0
- Mixed Contacts
- NO
- Iec Conformance
- NO
- Sıra Sayısı
- 2
- Flammability Rating
- UL94 V-0
- Option
- GENERAL PURPOSE
- Akım Değeri
- 200mA
- Ambalaj
- Tape & Reel (TR)
- Total Number Of Contacts
- 7
- Ul Flammability Code
- 94V-0
- Seri
- Y3B
- Pitch
- 0.012 0.30mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pozisyon Sayısı
- 7
- Yayın Yılı
- 2000
- JESD-609 Kodu
- e4
- Contact Finish Thickness
- Flash
- Cable End Type
- Tapered
- Mil Conformance
- NO
