Specifications
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2008
- Ul Flammability Code
- 94V-0
- Mixed Contacts
- NO
- Kurşunsuz
- Lead Free
- JESD-609 Kodu
- e4
- Max Current Rating
- 5A
- Ambalaj
- Tape & Reel (TR)
- Contact Materials
- Copper
- Min. Çalışma Sıcaklığı
- -55°C
- Depth
- 3.12mm
- Parça Durumu
- Obsolete
- Housing Material
- Polymer
- Height Above Board
- 0.052 1.32mm
- Pitch
- 0.016 0.40mm
- Max Voltage Rating Ac
- 60V
- Option
- GENERAL PURPOSE
- Orientation
- Straight
- Mil Conformance
- NO
- Maks. Çalışma Sıcaklığı
- 85°C
- Connector Type
- Header, Outer Shroud Contacts
- Radyasyon Dayanımı
- No
- Nominal Gerilim
- 60V
- Max Voltage Rating Dc
- 6.06kV
- Din Conformance
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Seri
- P4
- Sıra Sayısı
- 2
- Gender
- Male
- Housing Color
- Black
- Uzunluk
- 13.9mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8536.69.40.40
- Contact Resistance
- 70mOhm
- Terminal
- Solder
- Contact Finish
- Gold
- Total Number Of Contacts
- 64
- Pozisyon Sayısı
- 64
- Akım Değeri
- 300mA
- Iec Conformance
- NO
