Specifications
- Max Voltage Rating Ac
- 60V
- Additional Feature
- LOW PROFILE
- Housing Material
- Polymer
- Pcb Contact Pattern
- RECTANGULAR
- Depth
- 3.75mm
- Parça Durumu
- Active
- Insertion Forcemax
- .973 N
- Radyasyon Dayanımı
- No
- Maks. Çalışma Sıcaklığı
- 85°C
- Orientation
- Straight
- Option
- GENERAL PURPOSE
- Ul Flammability Code
- 94V-0
- Yayın Yılı
- 2008
- RoHS Durumu
- RoHS Compliant
- Contact Style
- BELLOWED TYPE
- Dielectric Withstanding Voltage
- 150VAC V
- Max Current Rating
- 5A
- JESD-609 Kodu
- e4
- Reference Standard
- UL
- Terminal
- Solder
- Contact Resistance
- 70mOhm
- Reliability
- COMMERCIAL
- Filter Feature
- NO
- Fabrika Tedarik Süresi
- 10 Weeks
- Montaj Tipi
- Surface Mount
- Akım Değeri
- 300mA
- Rated Current Signal
- 5A
- Pcb Contact Row Spacing
- 4.5974 mm
- Gender
- Female
- Polarization Key
- POLARIZED HOUSING
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Max Voltage Rating Dc
- 60V
- Din Conformance
- NO
- Pitch
- 0.016 0.40mm
- Height Above Board
- 0.059 1.50mm
- Number Of Conductors
- ONE
- Min. Çalışma Sıcaklığı
- -55°C
- Nominal Gerilim
- 60V
- Connector Type
- Socket, Center Strip Contacts
- Insulation Resistance
- 1000000000Ohm
