Volume pricing
- 1+ pcs$1.80
- 10+ pcs$1.70
- 100+ pcs$1.60
- 500+ pcs$1.51
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pretravel
- 0.087 (2.2mm)
- Yayın Yılı
- 2000
- Weight
- 200mg
- Montaj
- Through Hole
- Differential Travel
- 0.027 (0.7mm)
- Operating Position
- 0.240 (6.1mm)
- RoHS Durumu
- RoHS Compliant
- Contact Dc Max Rating R Load
- .5A@30VDC
- Max Voltage Rating Dc
- 30V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reach Svhc
- Unknown
- Terminal Stili
- PC Pin
- Overtravel
- 0.011 (0.3mm)
- Actuator Type
- Lever, Simulated Roller
- Contact Plating
- Silver
- Electricallife
- 20,000 Cycles
- Contact Current Rating
- 500mA
- Parça Durumu
- Active
- Terminal
- PC Pin
- Orientation
- Straight
- Body Length Or Diameter
- 7.5mm
- HTS Kodu
- 8536.50.70.00
- Pozisyon Sayısı
- 2
- Mechanical Life
- 300,000 Cycles
- Contact Materials
- Silver, Stainless Steel
- ECCN Kodu
- EAR99
- Montaj Tipi
- Through Hole
- Body Height
- 4.5mm
- Voltage Rated Dc
- 30V
- Ambalaj
- Bulk
- Operating Force
- 29gf
- Circuit
- SPDT
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 500mA
- Switch Function
- On-Mom
- Seri
- AV4
- Housing Material
- Plastic
- Current Rating Amps
- 500mA DC
- Kurşunsuz
- Lead Free
- Contact Currentdcmax
- 0.5A
