Specifications
- Actuator Type
- Lever, Simulated Roller
- Max Voltage Rating Dc
- 30V
- Overtravel
- 0.011 (0.3mm)
- Terminal Stili
- Solder Lug
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Contact Current Rating
- 100mA
- Terminal
- Solder
- Orientation
- Straight
- Contact Plating
- Gold
- Electricallife
- 200,000 Cycles
- Uzunluk
- 7.5mm
- Operating Position
- 0.264 (6.7mm)
- Max Current Rating
- 100mA
- Yayın Yılı
- 2000
- Pretravel
- 0.087 (2.2mm)
- Differential Travel
- 0.027 (0.7mm)
- Weight
- 300mg
- Montaj
- Chassis Mount, Screw, Solder
- Contact Dc Max Rating R Load
- .1A@30VDC
- RoHS Durumu
- RoHS Compliant
- Kılıf / Paket
- 100
- Housing Material
- Plastic
- Switch Function
- On-Mom
- Seri
- AV4
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Circuit
- SPDT
- Operating Force
- 29gf
- Akım Değeri
- 100mA
- Çalışma Sıcaklığı
- -25°C~80°C
- JESD-609 Kodu
- e4
- Kurşunsuz
- Lead Free
- Current Rating Amps
- 100mA DC
- Fabrika Tedarik Süresi
- 12 Weeks
- Contact Currentdcmax
- 0.1A
- Contact Materials
- Gold, Stainless Steel
- ECCN Kodu
- EAR99
- Depth
- 2.5mm
- Montaj Tipi
- Chassis Mount
- Mechanical Life
- 300,000 Cycles
