Specifications
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Ambalaj
- Bulk
- Overtravel
- 0.083 (2.1mm)
- Yüzey Montaj
- NO
- Terminal
- Quick Connect
- Fabrika Tedarik Süresi
- 12 Weeks
- HTS Kodu
- 8536.50.90.55
- Current Rating Amps
- 10A AC
- Additional Feature
- UL, CSA, VDE, SEMKO APPROVED
- Montaj Tipi
- Panel Mount, Snap-In
- Yayın Yılı
- 2000
- Contact Resistance
- 0.1mOhm
- Seri
- AV1
- Contact Currentacmax
- 10A
- Çalışma Sıcaklığı
- -25°C~85°C
- Contact Current Rating
- 10.1A
- Operating Position
- 0.366 (9.3mm)
- Dielectric Withstanding Voltage
- 2500VRMS V
- Reach Svhc
- Unknown
- Body Length Or Diameter
- 39.9034mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ingress Protection
- IP40
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Body Breadth
- 17.399 mm
- Throw Configuration
- DPST
- Voltage Rated Ac
- 250V
- Contact Materials
- Cadmium, Silver
- Body Height
- 39.5986mm
- Mechanical Life
- 1,000,000 Cycles
- Insulation Resistance
- 100000000Ohm
- Parça Durumu
- Active
- Contact Timing
- SNAP ACTION
- Contact Ac Max Rating R Load
- 10A@250VAC
- Akım Değeri
- 10.1A
- Operating Force
- 800gf
- Actuator Type
- Round (Pin Plunger)
- Circuit
- DPST-NO
- Özellikler
- Button Guard
- Electricallife
- 100,000 Cycles
