Specifications
- Overtravel
- 0.110 (2.8mm)
- Contact Materials
- Gold
- Ratings
- IP67
- Terminal
- Solder
- Body Height
- 9.3mm
- Akım Değeri
- 100mA
- Max Voltage Rating Dc
- 30V
- Voltage Rated Ac
- 20V
- Reach Svhc
- Unknown
- RoHS Durumu
- RoHS Compliant
- Body Breadth
- 5.4 mm
- Circuit
- SPDT
- Yayın Yılı
- 2008
- Switch Function
- On-Mom
- Orientation
- Straight
- Pretravelmax
- 10.1 mm
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Montaj Tipi
- Chassis Mount
- Operating Force
- 153gf
- Operating Position
- 0.472 (12.0mm)
- Current Rating Amps
- 100mA DC
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Kurşunsuz Kodu
- yes
- Contact Currentdcmax
- 0.1A
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~85°C
- Seri
- ASQ1
- Fabrika Tedarik Süresi
- 12 Weeks
- ECCN Kodu
- EAR99
- Actuator Travel
- 8.7 mm
- Body Length Or Diameter
- 13.3mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal Stili
- Solder Lug
- Kılıf / Paket
- 100
- Electricallife
- 200,000 Cycles
- Contact Dc Max Rating R Load
- .1A@30VDC
- Voltage Rated Dc
- 30V
- Actuator Type
- Lever, Simulated Roller
