APV1121S

Specifications

Fabrika Tedarik Süresi

12 Weeks

Çıkış Tipi

Photovoltaic

Rise Time

400μs

Reverse Voltage Dc

5V

Output Voltage

8.7V

Fall Time Typ

100 μs

Configuration

SINGLE

Forward Current

50mA

Fonksiyon Sayısı

1

Turn On Turn Off Time Typ

400μs, 100μs

Reach Svhc

No SVHC

Nem Hassasiyeti (MSL)

2A (4 Weeks)

Load Current

14μA

Usage Level

Industrial grade

Montaj

Surface Mount

Ambalaj

Tube

Output Current

14μA

Max Power Dissipation

75mW

Number Of Channels

1

Kurşunsuz

Lead Free

Pin Sayısı

4

Output Current Per Channel

14μA

Giriş Tipi

DC

Voltage Rated Dc

2.5kV

Power Dissipation

75mW

Voltage Forward Vf Typ

1.15V

Reverse Breakdown Voltage

5V

Rms Current Irms

14mA

Radyasyon Dayanımı

No

Max Input Current

50mA

Max Output Voltage

8.7V

Voltage Isolation

2500Vrms

Çalışma Sıcaklığı

-40°C~85°C

Montaj Tipi

Surface Mount

Optoelectronic Device Type

OPTOELECTRONIC DEVICE

Parça Durumu

Active

Kılıf / Paket

4-SMD, Gull Wing

Yayın Yılı

2008

RoHS Durumu

RoHS Compliant
