Specifications
- RoHS Durumu
- RoHS Compliant
- Number Of Elements
- 1
- Max Output Current
- 100mA
- Fabrika Tedarik Süresi
- 10 Weeks
- Voltage Isolation
- 5000Vrms
- Turn On Time
- 100μs (Max)
- Power Dissipation
- 500mW
- Output Current
- 100mA
- Kurşunsuz
- Lead Free
- Load Current
- 100mA
- Onay Kuruluşu
- cUR, VDE
- Voltage Forward Vf Typ
- 1.21V
- Reverse Breakdown Voltage
- 6V
- Max Input Voltage
- 1.3V
- Terminal
- Through Hole
- Turn On Delay Time
- 100 μs
- Uzunluk
- 8.8mm
- Reach Svhc
- No SVHC
- Pin Sayısı
- 6
- Seri
- APT
- Currentled Triggeriftmax
- 10mA
- Depth
- 6.4mm
- Additional Feature
- UL RECOGNIZED, VDE APPROVED
- Zerocrossing Circuit
- No
- Parça Durumu
- Active
- Onstate Voltagemax
- 2.5V
- Currentholdih
- 3.5mA
- Montaj
- PCB, Through Hole
- Rms Current Irms
- 100mA
- Input Trigger Currentnom
- 10mA
- Throw Configuration
- SPST
- Çalışma Sıcaklığı
- -40°C~100°C
- Max Output Voltage
- 600V
- Max Power Dissipation
- 500mW
- Input Current
- 20mA
- Output Current Per Channel
- 100mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Channels
- 1
- Kılıf / Paket
- 6-DIP (0.300, 7.62mm)
- Yükseklik
- 3.4mm
