Volume pricing
- 1+ pcs$22.66
- 10+ pcs$21.37
- 100+ pcs$20.16
- 500+ pcs$19.02
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mounting Feature
- THROUGH HOLE-STRAIGHT MOUNT
- RoHS Durumu
- RoHS Compliant
- Contact Resistance
- 100mOhm
- Release Time
- 5 ms
- Relay Action
- MOMENTARY
- Coil Voltage
- 48V
- Insulation Resistance
- 1000000000Ohm
- REACH Uyumluluk Kodu
- unknown
- Power Rating
- 400mW
- Reference Standard
- UL; VDE
- Min. Çalışma Sıcaklığı
- -40°C
- Coilresistance
- 5.76kOhm
- Additional Feature
- LOW PROFILE
- Pcb Hole Count
- 6
- Maks. Çalışma Sıcaklığı
- 105°C
- Body Height
- 15.7mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Relay Type
- POWER/SIGNAL RELAY
- Fabrika Tedarik Süresi
- 24 Weeks
- Throw Configuration
- SPST
- Pin Sayısı
- 6
- Operate Time
- 15 ms
- Relay Form
- 1 FORM A
- Max Voltage Rating Ac
- 440V
- Body Breadth
- 12.5 mm
- Terminal Sayısı
- 6
- Body Length Or Diameter
- 28.8mm
- Termination Type
- SOLDER
- Physical Dimension
- 28.8mm x 12.5mm x 15.7mm
- Max Current Rating
- 16A
- Weight
- 12g
- ECCN Kodu
- EAR99
- Dielectric Strength Between Open Contacts
- 1000 Vrms
- End Contact Material
- Silver Tin Oxide
- Length Termination
- 0.0035 inch
- Kurşunsuz
- Lead Free
- Input Switching Control Type
- Random
- Packing Method
- TUBE
- Dielectric Strength Between Coil And Contacts
- 5000 Vrms
- Parça Durumu
- Active
