Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -25°C~85°C
- Montaj Tipi
- Chassis Mount
- Orientation
- Straight
- Seri
- AH1
- Akım Değeri
- 1A
- Mechanical Life
- 1,000,000 Cycles
- Terminal Stili
- Solder Lug
- Max Voltage Rating Dc
- 30V
- Fabrika Tedarik Süresi
- 12 Weeks
- Release Force
- 10gf
- Voltage Rated Ac
- 125V
- Overtravel
- 0.010 (0.25mm)
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Electricallife
- 30,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Dc
- 30V
- Max Voltage Rating Ac
- 125V
- Ratings
- IP40
- Min. Çalışma Sıcaklığı
- -25°C
- Operating Force
- 74gf
- Parça Durumu
- Active
- Operating Position
- 0.217 (5.5mm)
- Throw Configuration
- SPDT
- Kurşunsuz
- Lead Free
- Ambalaj
- Tube
- Differential Travel
- 0.005 (0.12mm)
- Circuit
- SPDT
- Current Rating Amps
- 1A AC/DC
- Switch Function
- On-Mom
- Maks. Çalışma Sıcaklığı
- 85°C
- Terminal
- Solder
- Pretravel
- 0.020 (0.5mm)
- Actuator Type
- Round (Pin Plunger)
- Contact Current Rating
- 1A
- Contact Materials
- Silver
