Specifications
- Çalışma Sıcaklığı
- -40°C~80°C
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Must Release Voltage
- 3.84VDC
- Packing Method
- BOX
- Coil Type
- Non Latching
- Contact Voltagedcmax
- 400V
- Coil Current
- 26mA
- Kontak Formu
- SPST-NO (1 Form A)
- Montaj
- Chassis Mount
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Body Length Or Diameter
- 45mm
- Reference Standard
- UL
- Seri
- AEP
- ECCN Kodu
- EAR99
- Relay Type
- Automotive
- Coil Voltage Dc
- 48V
- Operate Time
- 50ms
- Electricallife
- 75000 Cycle(s)
- Sealing
- HERMETICALLY SEALED
- Fabrika Tedarik Süresi
- 13 Weeks
- Throw Configuration
- SPST
- Coilinput Supply Type
- DC
- Coilresistance
- 1846.15Ohm
- Contact Rating Current
- 10A
- Switching Voltage
- 400VDC - Nom
- REACH Uyumluluk Kodu
- unknown
- Physical Dimension
- 45mm x 37.9mm x 31.7mm
- Yayın Yılı
- 2012
- Contactoutput Supply Type
- DC
- Release Time
- 30ms
- Coil Voltage
- 48VDC
- Terminal
- Quick Connect
- Relay Action
- MOMENTARY
- Coil Power
- 1.4W
- Body Breadth
- 37.9 mm
- Body Height
- 31.7mm
- Must Operate Voltage
- 36VDC
- Özellikler
- Sealed - Hermetically
