Specifications
- ECCN Kodu
- EAR99
- Relay Form
- 1 FORM A
- Terminal Sayısı
- 3
- Relay Type
- POWER/SIGNAL RELAY
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 11 Weeks
- Contact Ac Max Rating R Load
- 120A@250VAC
- Body Length Or Diameter
- 41mm
- Operating Temperature Min
- -40°C
- Contact Voltageacmax
- 250V
- Body Breadth
- 35 mm
- Coil Voltagedcmax
- 15.6V
- Operate Time
- 20 ms
- Coil Operate Voltagedc
- 8.4V
- Coil Voltage
- 12V
- Weight
- 75g
- Parça Durumu
- Obsolete
- Pcb Hole Count
- 3
- Dielectric Strength Between Coil And Contacts
- 4000 Vrms
- Input Switching Control Type
- Random
- RoHS Durumu
- RoHS Compliant
- End Contact Material
- Silver Tin Oxide
- Contactoutput Supply Type
- AC
- Operating Temperature Max
- 85°C
- Coilresistance
- 102.9Ohm
- Coilinput Supply Type
- DC
- Dielectric Strength Between Open Contacts
- 2000 Vrms
- Release Time
- 20 ms
- Physical Dimension
- 41mm x 35mm x 22mm
- Electricallife
- 10000 Cycle(s)
- Throw Configuration
- SPST
- Body Height
- 22mm
- Insulation Resistance
- 1000000000Ohm
- Termination Type
- SOLDER
- Contact Currentacmax
- 120A
- Yayın Yılı
- 2000
- Coil Release Voltagedc
- 8.4V
- REACH Uyumluluk Kodu
- unknown
