Specifications
- Contactoutput Supply Type
- DC
- Max Voltage Rating Dc
- 14V
- Insulation Resistance
- 20000000Ohm
- Must Release Voltage
- 0.5VDC
- Body Height
- 15.7mm
- Max Current Rating
- 35A
- Coilinput Supply Type
- DC
- ECCN Kodu
- EAR99
- Throw Configuration
- SPST
- Must Operate Voltage
- 7VDC
- Uzunluk
- 22.5mm
- Coil Voltage
- 12VDC
- Seri
- ACVN
- Physical Dimension
- 22.5mm x 15mm x 15.7mm
- Coil Power
- 800mW
- Input Switching Control Type
- Random
- Contact Materials
- Silver Alloy, Cadmium Free
- Coil Voltage Dc
- 12V
- Weight
- 12g
- Terminal
- Plug
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operate Time
- 10ms
- Kontak Formu
- SPST-NO (1 Form A)
- Contact Dc Max Rating R Load
- 35A@14VDC
- Terminal Sayısı
- 4
- Dielectric Strength Between Coil And Contacts
- 500 Vrms
- Özellikler
- Sealed - Fully
- Terminal Stili
- Plug In
- Çalışma Sıcaklığı
- -40°C~85°C
- Electricallife
- 100000 Cycle(s)
- Switching Voltage
- 14VDC - Nom
- Coil Current
- 66.7mA
- Contact Resistance
- 3mOhm
- Body Breadth
- 15 mm
- Fabrika Tedarik Süresi
- 16 Weeks
- Coil Type
- Non Latching
- RoHS Durumu
- RoHS Compliant
- Coilresistance
- 180Ohm
- Release Time
- 10 ms
- Parça Durumu
- Active
