Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Coil Voltage Dc
- 12V
- Contact Materials
- Silver Alloy, Cadmium Free
- Contact Voltagedcmax
- 14V
- Operate Time
- 10ms
- Sealing
- EPOXY TERMINAL SEALED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Plug
- Contact Rating Current
- 20A
- Coilinput Supply Type
- DC
- Body Height
- 15.7mm
- Must Release Voltage
- 0.6VDC
- Contactoutput Supply Type
- DC
- Relay Action
- MOMENTARY
- Physical Dimension
- 22.5mm x 15mm x 15.7mm
- Coil Voltage
- 12VDC
- Seri
- ACV
- Must Operate Voltage
- 7VDC
- Throw Configuration
- SPDT
- ECCN Kodu
- EAR99
- Montaj Tipi
- Socketable
- Ambalaj
- Tube
- Parça Durumu
- Obsolete
- Relay Type
- Automotive
- Release Time
- 15 ms
- Coilresistance
- 180Ohm
- RoHS Durumu
- RoHS Compliant
- Coil Type
- Non Latching
- REACH Uyumluluk Kodu
- unknown
- Body Length Or Diameter
- 22.5mm
- Power Consumption
- 800mW
- Electricallife
- 100000 Cycle(s)
- Çalışma Sıcaklığı
- -40°C~85°C
- Terminal Stili
- Plug In
- Özellikler
- Diode
- Contact Dc Max Rating R Load
- 10A@14VDC
- Kontak Formu
- SPDT (1 Form C)
- Yayın Yılı
- 2006
- Body Breadth
- 15 mm
- Coil Current
- 67mA
