Specifications
- Kurşunsuz
- Lead Free
- Operate Time
- 10ms
- Yayın Yılı
- 1998
- Uzunluk
- 17.4mm
- Weight
- 8g
- Coilresistance
- 180Ohm
- Switching Voltage
- 14VDC - Nom
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- Silver Alloy, Cadmium Free
- Radyasyon Dayanımı
- No
- Yükseklik
- 13.5mm
- Coil Voltage Dc
- 12V
- Pin Sayısı
- 10
- Montaj Tipi
- Through Hole
- Relay Type
- Automotive
- Terminal Stili
- PC Pin
- Physical Dimension
- 17.4mm x 14mm x 13.5mm
- Must Release Voltage
- 1VDC
- Fabrika Tedarik Süresi
- 16 Weeks
- HTS Kodu
- 8536.41.00.05
- Coil Type
- Non Latching
- Çalışma Sıcaklığı
- -40°C~85°C
- ECCN Kodu
- EAR99
- Must Operate Voltage
- 7.2VDC
- Depth
- 14mm
- Max Voltage Rating Dc
- 14V
- Sealing
- EPOXY RESIN SEALED
- Coil Voltage
- 12VDC
- Coilinput Supply Type
- DC
- Throw Configuration
- SPDT
- Contactoutput Supply Type
- DC
- Kontak Formu
- SPDT (1 Form C) x 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Through Hole
- Contact Rating Current
- 20A
- Voltage Rated Dc
- 14V
- Genişlik
- 14mm
- Seri
- ACT
- Relay Action
- MOMENTARY
