Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Box
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Coilinput Supply Type
- DC
- Contactoutput Supply Type
- DC
- Özellikler
- Sealed - Fully
- ECCN Kodu
- EAR99
- Packing Method
- TUBE
- Max Voltage Rating Dc
- 14V
- Coil Voltage Dc
- 12V
- Kontak Formu
- SPDT (1 Form C) x 2
- Terminal Stili
- PC Pin
- Must Operate Voltage
- 7.2VDC
- Coil Voltage
- 12VDC
- Parça Durumu
- Active
- Throw Configuration
- SPDT
- Yayın Yılı
- 2000
- Coilresistance
- 225Ohm
- Operate Time
- 10ms
- Sealing
- EPOXY TERMINAL SEALED
- Body Length Or Diameter
- 14.4mm
- Switching Voltage
- 14VDC - Nom
- Contact Materials
- Silver Alloy, Cadmium Free
- Weight
- 6.5g
- Must Release Voltage
- 1VDC
- Terminal
- Solder
- Fabrika Tedarik Süresi
- 16 Weeks
- Coil Current
- 53.3mA
- Coil Power
- 640mW
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Relay Action
- MOMENTARY
- Contact Rating Current
- 20A
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 10
- HTS Kodu
- 8536.41.00.05
- Coil Type
- Non Latching
- Body Breadth
- 12.2 mm
- Seri
- ACJ
- Physical Dimension
- 14.4mm x 12.2mm x 13.5mm
- Body Height
- 13.5mm
