Volume pricing
- 1+ pcs$3.10
- 10+ pcs$2.92
- 100+ pcs$2.76
- 500+ pcs$2.60
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Dc Max Rating R Load
- .1A@30VDC
- Switch Function
- On-Mom
- Akım Değeri
- 100mA
- Circuit
- SPDT
- Max Voltage Rating Dc
- 30V
- Operating Force
- 60gf
- Contact Materials
- Gold
- Depth
- 22.33mm
- HTS Kodu
- 8536.50.70.00
- Ingress Protection
- IP50 - Dust Protected
- Differential Travel
- 0.020 (0.5mm)
- Çalışma Sıcaklığı
- -40°C~85°C
- Contact Currentdcmax
- 0.1A
- Montaj Tipi
- Through Hole, Right Angle
- Overtravel
- 0.032 (0.81mm)
- Özellikler
- Actuator Mounted Right Side
- Ambalaj
- Bulk
- Weight
- 2g
- Electricallife
- 200,000 Cycles
- Montaj
- Through Hole
- Max Current Rating
- 100mA
- Terminal
- PC Pin
- Pretravelmax
- 2.5 mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Type
- Lever, Roller
- Voltage Rated Dc
- 30V
- Sealing
- ENVIRONMENTALLY SEALED; IP67
- ECCN Kodu
- EAR99
- Terminal Stili
- PC Pin
- Mechanical Life
- 5,000,000 Cycles
- Operating Position
- 0.571 (14.5mm)
- Fabrika Tedarik Süresi
- 11 Weeks
- Actuator Travel
- 3.3 mm
- Seri
- ABS
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2012
- Body Breadth
- 11.1 mm
- Release Force
- 4.079gf
- Parça Durumu
- Active
- JESD-609 Kodu
- e4
