Specifications
- Parça Durumu
- Obsolete
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Mechanical Life
- 5,000,000 Cycles
- Contact Currentacmax
- 2A
- Contact Current Rating
- 2A
- Body Breadth
- 6.4 mm
- Contact Ac Max Rating R Load
- 2A@250VAC
- Seri
- ABS
- Pretravelmax
- 2.5 mm
- RoHS Durumu
- RoHS Compliant
- Actuator Type
- Lever, Roller
- Contact Currentdcmax
- 2A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Chassis Mount
- Operating Force
- 40gf
- HTS Kodu
- 8536.50.70.00
- Montaj
- Chassis Mount, Screw, Wire
- Max Voltage Rating Dc
- 125V
- Circuit
- SPDT
- Switch Function
- On-Mom
- Release Force
- 3.500gf
- Voltage Rated Ac
- 125V
- Terminal Stili
- Wire Leads
- Ambalaj
- Bulk
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Voltage Rated Dc
- 30V
- Pretravel
- 0.100 (2.5mm)
- Current Rating Amps
- 2A AC/DC
- Insulation Resistance
- 100MOhm
- Reach Svhc
- No SVHC
- Orientation
- Straight
- Actuator Travel
- 3.3 mm
- Contact Dc Max Rating R Load
- 2A@30VDC
- Yayın Yılı
- 2001
- Sealing
- ENVIRONMENTALLY SEALED; IP67
- Differential Travel
- 0.020 (0.5mm)
- Max Voltage Rating Ac
- 250V
- Operating Position
- 0.571 (14.5mm)
- Contact Resistance
- 100mOhm
- Terminal
- Wire Leads
