Volume pricing
- 1+ pcs$2.78
- 10+ pcs$2.62
- 100+ pcs$2.47
- 500+ pcs$2.33
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- JESD-609 Kodu
- e4
- HTS Kodu
- 8536.50.70.00
- Current Rating Amps
- 1A AC/DC
- Fabrika Tedarik Süresi
- 11 Weeks
- Max Voltage Rating Dc
- 30V
- Terminal
- Solder
- Pretravelmax
- 0.6 mm
- Çalışma Sıcaklığı
- -40°C~85°C
- Operating Position
- 0.276 (7.0mm)
- Contact Currentacmax
- 1A
- Max Voltage Rating Ac
- 125V
- Yayın Yılı
- 2005
- Seri
- ABJ
- Ratings
- IP50, IP67
- Ingress Protection
- IP50 - Dust Protected
- Actuator Travel
- 0.85 mm
- Body Breadth
- 6 mm
- Differential Travel
- 0.005 (0.12mm)
- Akım Değeri
- 1A
- Kurşunsuz
- Lead Free
- Contact Materials
- Silver
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Electricallife
- 30,000 Cycles
- Overtravel
- 0.010 (0.25mm)
- Terminal Stili
- Solder Lug
- Ambalaj
- Bulk
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Contact Currentdcmax
- 1A
- Contact Current Rating
- 1A
- Release Force
- 15gf
- Contact Dc Max Rating R Load
- 1A@30VDC
- Weight
- 500mg
- Orientation
- Straight
- Montaj Tipi
- Chassis Mount
- Voltage Rated Dc
- 30V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Body Length Or Diameter
- 12.8mm
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Contact Ac Max Rating R Load
- 1A@125VAC
