Specifications
- Pretravelmax
- 0.6 mm
- Ratings
- IP50, IP67
- Montaj Tipi
- Chassis Mount
- Orientation
- Straight
- Seri
- ABJ
- Weight
- 500mg
- Contact Dc Max Rating R Load
- 2A@30VDC
- Contact Currentacmax
- 2A
- Max Voltage Rating Ac
- 125V
- Operating Position
- 0.217 (5.5mm)
- Release Force
- 25gf
- Çalışma Sıcaklığı
- -40°C~85°C
- JESD-609 Kodu
- e4
- Contact Currentdcmax
- 2A
- Ambalaj
- Bulk
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Terminal Stili
- Solder Lug
- Overtravel
- 0.010 (0.25mm)
- Terminal
- Solder
- Max Voltage Rating Dc
- 30V
- HTS Kodu
- 8536.50.70.00
- Current Rating Amps
- 2A AC/DC
- Body Height
- 6.5mm
- Pretravel
- 0.024 (0.6mm)
- Contact Materials
- Silver
- Voltage Rated Ac
- 125V
- Mechanical Life
- 1,000,000 Cycles
- Kurşunsuz
- Lead Free
- Akım Değeri
- 2A
- Contact Ac Max Rating R Load
- 2A@125VAC
- Parça Durumu
- Obsolete
- Actuator Type
- Round (Pin Plunger)
- Operating Force
- 200gf
- Circuit
- SPDT
- Electricallife
- 6,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Function
- On-Mom
- Actuator Travel
- 0.85 mm
- Body Length Or Diameter
- 12.8mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
