Specifications
- RoHS Durumu
- ROHS3 Compliant
- Onay Kuruluşu
- cURus, TUV
- Parça Durumu
- Active
- Voltage Range
- 7V~17VDC
- Seri
- OD9225
- Boyut / Ölçü
- Square - 92.5mm Lx92.5mm H
- Terminal
- 2 Wire Leads
- Yükseklik
- 92.5mm
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2010
- Operating Supply Voltage
- 12V
- Power Rating
- 2.04W
- Lifetime Temp
- 60000 Hrs @ 40°C
- Çalışma Sıcaklığı
- -4~176°F -20°C~80°C
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Housing Material
- Plastic
- Power Consumption
- 2W
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Noise
- 31.0 dB
- Current Rating Amps
- 0.170A
- Fabrika Tedarik Süresi
- 19 Weeks
- Fan Type
- Tubeaxial
- Depth
- 25mm
- Static Pressure
- 0.090 in H2O (22.4 Pa)
- Nominal Gerilim
- 12VDC
- Rpm
- 2400 RPM
- Kılıf / Paket
- Axial
- Akım Değeri
- 170mA
- Bearing Type
- Ball
