Volume pricing
- 1+ pcs$10.63
- 10+ pcs$10.03
- 100+ pcs$9.46
- 500+ pcs$8.93
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Onay Kuruluşu
- cURus, TUV
- RoHS Durumu
- ROHS3 Compliant
- Voltage Range
- 8V~16VDC
- Ambalaj
- Box
- Parça Durumu
- Active
- Boyut / Ölçü
- Square - 92mm Lx92mm H
- Seri
- OD9220
- Terminal
- 2 Wire Leads
- Yayın Yılı
- 2010
- Kurşunsuz
- Lead Free
- Yükseklik
- 92mm
- Power Rating
- 290mW
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Lifetime Temp
- 65000 Hrs @ 45°C
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Plastic
- Noise
- 33.0 dB
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Fan Type
- Tubeaxial
- Current Rating Amps
- 0.250A
- Fabrika Tedarik Süresi
- 19 Weeks
- Static Pressure
- 0.130 in H2O (32.4 Pa)
- Rpm
- 2700 RPM
- Nominal Gerilim
- 12VDC
- Kılıf / Paket
- Axial
- Akım Değeri
- 250mA
- Bearing Type
- Ball
