Specifications
- Static Pressure
- 0.290 in H2O (72.2 Pa)
- Current Rating Amps
- 0.120A
- Fabrika Tedarik Süresi
- 19 Weeks
- Depth
- 32mm
- Fan Type
- Tubeaxial
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Noise
- 42.0 dB
- Montaj
- Flanges
- Power Consumption
- 2.2W
- Housing Material
- Plastic
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Bearing Type
- Ball
- Akım Değeri
- 380mA
- Kılıf / Paket
- Axial
- Nominal Gerilim
- 24VDC
- Rpm
- 3800 RPM
- Thickness
- 32mm
- Seri
- OD8032
- Boyut / Ölçü
- Square - 80.5mm Lx80.5mm H
- Parça Durumu
- Active
- Voltage Range
- 21.6V~26.4VDC
- RoHS Durumu
- ROHS3 Compliant
- Onay Kuruluşu
- cURus, TUV
- Çalışma Sıcaklığı
- -4~158°F -20°C~70°C
- Lifetime Temp
- 70000 Hrs @ 40°C
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Operating Supply Voltage
- 24V
- Power Rating
- 380mW
- Yükseklik
- 80.5mm
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2011
- Terminal
- 2 Wire Leads
