Volume pricing
- 1+ pcs$17.89
- 10+ pcs$16.88
- 100+ pcs$15.92
- 500+ pcs$15.02
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Static Pressure
- 0.320 in H2O (79.7 Pa)
- Fan Type
- Tubeaxial
- Fabrika Tedarik Süresi
- 19 Weeks
- Current Rating Amps
- 0.230A
- Noise
- 44.0 dB
- Material Blade
- Polybutylene Terephthalate (PBT)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Bearing Type
- Ball
- Akım Değeri
- 230mA
- Weight
- 0.238lb 107.95g
- Rpm
- 4200 RPM
- Nominal Gerilim
- 12VDC
- Max Power Dissipation
- 4.56W
- Özellikler
- Locked Rotor Sensor
- Boyut / Ölçü
- Square - 80mm Lx80mm H
- Seri
- OD8032
- Voltage Range
- 7V~13.2VDC
- Parça Durumu
- Active
- Onay Kuruluşu
- CE, cURus
- RoHS Durumu
- ROHS3 Compliant
- Material Frame
- Polybutylene Terephthalate (PBT)
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Lifetime Temp
- 70000 Hrs @ 40°C
- Yayın Yılı
- 2010
- Terminal
- 3 Wire Leads
