Volume pricing
- 1+ pcs$11.96
- 10+ pcs$11.28
- 100+ pcs$10.65
- 500+ pcs$10.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Noise
- 35.0 dB
- Static Pressure
- 0.160 in H2O (39.8 Pa)
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 3100 RPM
- Yayın Yılı
- 2010
- Current Rating Amps
- 0.110A
- Özellikler
- Auto Restart, Speed Sensor (Tach)
- Lifetime Temp
- 65000 Hrs @ 45°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- PBT
- Material Blade
- Polybutylene Terephthalate (PBT)
- Seri
- OD8025
- Terminal
- 3 Wire Leads
- Power Rating
- 110mW
- Akım Değeri
- 110mA
- Power Consumption
- 2.41W
- Kılıf / Paket
- Axial
- Fan Type
- Tubeaxial
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -4~167°F -20°C~75°C
- Yükseklik
- 80mm
- Material Frame
- Polybutylene Terephthalate (PBT)
- Depth
- 25mm
- Material
- Plastic
- Max Power Dissipation
- 2.41W
- Güç (Watt)
- 1.44W
- Onay Kuruluşu
- cURus, TUV
- Operating Supply Voltage
- 24V
- Boyut / Ölçü
- Square - 80mm Lx80mm H
- Nominal Gerilim
- 24VDC
- Bearing Type
- Ball
- Weight
- 0.191lb 86.64g
- Fabrika Tedarik Süresi
- 19 Weeks
- Parça Durumu
- Active
